Textile Laboratory Testing Equipment Aatcc Washer (3LWTW 4815FW) D029A
Overview
Selected and certified for AATCC Test methods requiring repeated home laundering (methods 88 B+C, 124, 130, 135, 142, 143, 150, 172 and 179) for textiles, knitted fabrics and woven to do stretch and recovery property test. Available in US domestic and international electrical specifications.
Application
Textiles
Fabrics
Standards
AATCC 88BAATCC 88CAATCC 124
AATCC 130AATCC 135AATCC 142
AATCC 143AATCC 150AATCC 172
AATCC 179AATCC 159AATCC 188
Key Parameters
|
Model |
D029A(3LWTW4815FW) |
|
Washing capacity |
15kg/33lb |
|
No. Of washing programs |
12+ |
|
No. Of washing options |
3 |
|
Solil level options |
3 |
|
Temperature options |
4 |
|
Color of machine |
White |
|
Power supply |
220-240V, 50Hz, 13A, 800W |
|
Product size |
1080 x 685 x 650(H x W x D)(mm) |
|
Packing carton size |
1120 x 720 x 720(H x W x D)(mm) |
|
Gross weight(Carton packing) |
62kg/63lb |
Product Details
Control panel
Production Processes
Process design and design and manufacture of specialized process equipment
Machining of components
Assembly of products
Comprehensive testing of machines
Scenarios of Use
Laboratory
Textile factory
Operation
Connecting the air supply
Connect the air supply to the instrument.
Add distilled water
Connect tube from the freestanding funnel to the water connector located at the back right-hand corner of the SST unit. Add distilled water.
Put in filte
Unscrew the screws and remove the top plate,Take away the reflector.
Put in filter.
Install the xenon lamp
Install the xenon lamp and connect the lamp cabler.Replace the top cover and tighten the set screws.
Mount the sample
Mount the sample on the sample clamp.
BPT Sampling
Place the sample into the test chamber and close the door.Be careful to avoid covering the BPT sensor.
Transportation
Packing System
1. Products are covered with air bubble film before put them into composite board standard export wooden case. To ensure waterproof, moistureproof, corrosion, anti-corrosion and security.
2. Package with shipping mark in line with International and national standards, which is easy for handling, loading and unloading.
3. Packing materials selected accorded with economic and safety requirements
4. Compliance with environmental requirements.
For Metal Box Package
For Carton Package
For Wooden Case
